file:ground_wall_insulation_magnetica_png
Drawing of an insulation system for random winding in a motor, with the following components outlined (drawing not to scale):
- copper wire (magnet wire)
- turn insulation (enamel)
You are permitted and indeed encouraged to use this image freely, for any legal purpose including commercial, and with any modifications (the permission is hereby given, so there is no need to ask for it explicitly again), but you MUST always give the following credits:
S. Zurek, Encyclopedia Magnetica, CC-BY-4.0
We would appreciate if you let us know of any use: info@e-magnetica.pl
