Litz wire under a microscope. There are 28 strands of 0.375 mm enamelled wire.
The wire is cut an an angle to its axis, to better illustrate the presence of enamel on each strand.
You are permitted and indeed encouraged to use this image freely, for any legal purpose including commercial, and with any modifications (the permission is hereby given, so there is no need to ask for it explicitly again), but you MUST always give the following credits:
S. Zurek, Encyclopedia Magnetica, CC-BY-4.0
We would appreciate if you let us know of any use: info@e-magnetica.pl
See also: litz_wire_microscope_1_magnetica.jpg
